Description
The Model PPM-T276A “2002″Ultra-high Pressure Hammer Union Pressure Transmitters have been designed specifically for for use in the extremely harsh conditions found in on-shore and off-shore oil and gas rigs. All-welded, stainless steel construction features special stainless steel anti-corrosion materialsto isolate corrosive or abrasive drilling mediafrom sensitive intemal electronics; materials maintain strength at higher temperatures toprovide reliable performance under demanding conditions.
| Tested Media | Wet Soil,Oil,Corrosive liquid and gas |
| Explosion-proof Signs | Ex ib llC T4 Gb |
| Measuring Range | 0~15000psi,20000psi，25000psi |
| Power Supply | 9-36VDC,5~12VDC |
| Output Signal | 4-20mA, 0-5VDC, 1-5VDC, 0-10VDC, mV |
| Non-Linearity | 0.10%FS/°C |
| Repeatability | 0.05%FS |
| Combined Accuracy | 0.5%FS |
| Long-Term Stability | 0.1%FS/Year（representative value） |
| Medium Temperature | -40～80℃ |
| Ambient Temperature | -40～80℃ |
| Response Time | ≤1mSec（representative value） |
| Insulation Resistance | ≥500 MΩ/100VDC |
| Safety overload pressure | 150%FS(1.5 Times Full Range) |
| Rupture pressure | 500%FS(5 Times Full Range) |
| Shock Limitation | About 10g/0～2000HZ |
| Impact Resistance | About 50g/1ms |
| Connection | Chuck type seal or specified |
| Wetted Materials | 17-4PH stainless steel |
| Relative Humidity | 0～100% RH |
| Degree of Protection | IP67 |
| Electrical Connection | Aviation connector or directly out of line |
The PPM-T276A “2002″Ultra-high Pressure Hammer Union Pressure Transmitter is extensively utilized in various oilfield operations, including:
●Oil well drilling and servicing
●Acidizing processes
●Choke manifold
●Resource extraction activities
●Hydraulic fracturing and cementing
●Service and cement trucks
●Standpipe monitoring
