PPM-DCBYLS-D Electromagnetic Flow Sensor

Test medium: Conductive liquid (conductivity not less than 2us/cm)
Pressure: -0.1MPa~6.3MPa
Electrical connection: M12-4 pin connector

Product Introduction

The PPM-DCBYLS-D is a customized small-diameter, low-conductivity electromagnetic flow sensor for liquid-cooled CDUs in data centers. Based on the Faraday principle of electromagnetic induction, it employs high-impedance signal acquisition and dual-frequency excitation technology to specifically address the issues of low conductivity in ethylene glycol-deionized water mixed coolants and zero-point drift in ordinary electromagnetic flowmeters. It can measure media with a minimum conductivity ≥1μS/cm, making it compatible with newly formulated low-conductivity ethylene glycol coolants. It features empty pipe detection and EMC interference immunity; outputs 4-20mA and RS485-Modbus RTU, allowing interface with PLC and DCIM data center management systems; and is powered by DC24V for continuous 24/7 operation.ProjectParameter.

Product Features

Compact size and easy installation
Ultra-low conductivity≥2us/cm
Zero straight pipe section

Infrared remote control available, easy to adjust

Technical Parameters

Project	Parameter
Model	PPM-DCBYLS-D (JB/T9248-2015)
Verification Standards	JJG1033-2007
Test medium	Conductive liquid (conductivity not less than 2us/cm)
Flowmeter liner	Polyetheretherketone (PEEK) lining
Flowmeter diameter	DN6~DN65
Pressure	-0.1MPa~6.3MPa
Electrode material	316L
Shell material	304、 316L
Electrical connection	M12-4 pin connector
Process connection	Threaded, clamped, and flanged options are available; other interfaces can be customized.
Accuracy level	±0.5%
Corresponding repeatability	≤0.1%
Output signal	4~20mA(Maximum load5000)
Communication Protocol	RS485(MODBUS)
Range ratio	1:150
Power supply	18~36VDC
Power consumption	<5W
Environmental conditions	Ambient temperature:-20°C~+65°C; Storage temperature:-25°C~+85°C relative humidity:5%~95%; Protection level:IP65/IP67
